Danfoss Nozzles

Danfoss Oil Nozzles in India
All Danfoss Oil Nozzles are extremely precise and meet the requirements of the actual EN-norm of a capacity tolerance of ±4%



Nozzles spray angle

The flow (in USGPH at 100 PSI = 6.895 bar)

Letters to identify the series of spray patterns

The Danfoss Trademark

Danfoss Oil Nozzles production code



Danfoss Oil nozzles type OD are designed for domes-tic and commercial high-pressure oil burners operating with light or heavy fuel. They are available with 4 diff erent spray angles, 3 spray patterns and sizes from 0.3 to 35.0 USgal/h.

As to construction and atomizing, the OD nozzle is the basic model for all Danfoss oil nozzles.



  Oil Nozzles Type OD
  View Design of Danfoss Oil Nozzles
  Technical Data Danfoss Oil Nozzle
  Danfoss Oil Nozzles Dimensions

All Nozzles Quality

Danfoss Nozzle is individually tested
Each nozzle is tested at several different production stages to assure perfect conformity with master nozzles of each series. Danfoss Nozzles are tested 100% in test oil for keeping the tolerances permitted. Beyond this, the atomizing patterns are tested visually for regularity and atomizing faults, if any.



View Chart of Danfoss Nozzles

Conversion table for  Danfoss oil nozzles

Danfoss oil nozzles Design Chart

Danfoss oil nozzles technical data Chart

Danfoss oil nozzles Dimensions chart

Danfoss Nozzle Spray Angles chart
Danfoss Nozzle Capacities chart



View Detail Danfoss Nozzle Charts

Type of Nozzles

Types of all Danfoss Oil Nozzles

DANFOSS OIL NOZZLE 19.50 X 60 B Series
DANFOSS OIL NOZZLE 1.50 X 60 B Series
DANFOSS OIL NOZZLE 1.35 X 60 B Series
DANFOSS OIL NOZZLE 0.45 X 60 EH Series
DANFOSS OIL NOZZLE 1.00 X 80 ES Series
DANFOSS OIL NOZZLE 0.60 X 60 EH Series
DANFOSS OIL NOZZLE 0.55 X 60 ES Series
DANFOSS OIL NOZZLE 0.65 X 80 LE Series
DANFOSS OIL NOZZLE 0.55 X 80 S Series
DANFOSS OIL NOZZLE 12.00 X 45 B Series
DANFOSS OIL NOZZLE 15.00 X 60 B Series
DANFOSS OIL NOZZLE 3.00 X 80 H Series
DANFOSS OIL NOZZLE 2.50 X 80 H Series
DANFOSS OIL NOZZLE 2.75 X 45 B Series
Danfoss oil nozzle Solide Cone 'R" Series
Danfoss nozzle Semi-Solid Cone "PLP" Series
Danfoss nozzle  Heavy Oil Nozzle Series and many more.... View All Series Danfoss Nozzle

We are Importers of Danfoss Oil Nozzles in India

We are Distributors of Danfoss Oil Nozzles in India

We are Stockies of Danfoss Oil Nozzles in India

Since 1996 - 97









Spray patterns and Spray Angles of oil nozzles - Danfoss Oil Nozzles

Industrial and Residential Oil Nozzles, Oil Burner Nozzles, Spray Nozzles, Water Nozzles, Burner Spares and Burner Nozzle in India

Danfoss industrial and domestic oil burner nozzles are available in a variety of spray patterns, spray angels and capacities.



Danfoss Nozzle "S" spray patterns



Danfoss Nozzle "H" spray patterns



Danfoss Nozzle "B" spray patterns



Danfoss Nozzle "N" spray patterns



Danfoss Nozzle Spray Angles 30°



Danfoss Nozzle Spray Angles 45°



Danfoss Nozzle Spray Angles 60°



Danfoss Nozzle Spray Angles 80°



Danfoss brass oil nozzles

Danfoss presents the well known “A” and “OD ” programs of brass oil nozzles. Above 3.00 USgal/h and below 0.4 USgal/h the “OD” type is used. Each nozzle is thoroughly tested both electronically and visually for function and uniformity. To optimize operating performance and out of consideration for the environment, we recommend changing the nozzle once a year.



The properties of the Danfoss oil nozzle appear on the nozzle markings. Danfoss Oil nozzles are available with different spray patterns and spray angles. These must fit the burner in question and of course also the combustion chamber of the boiler.

The designations of the spray patterns on Danfoss oil nozzles are S (Solid); H (Hollow) and B (Universal = semi solid). Other marks have similar designations.


Danfoss oil nozzle spray angles are normally 30°, 45°, 60° and 80°.
The function of the Danfoss oil nozzle : Fig. 1 shows the way the fuel oil runs through the oil nozzle: The fuel oil is put under pressure by the oil pump and runs into the oil nozzle and is filtered in the nozzle filter. In the swirl chamber the fuel oil “rotates” and leaves the oil nozzle for being burst in many fine small drops. The orifice and the cone slots determine the spray characteristics. Burners used today, designed exactly to the heat requirement of the house, have resulted in a reduction of the burner capacities. So the cross section in the oil nozzle had to be reduced, too.









View All Series of Danfoss Oil Nozzle



Marking of the Danfoss oil nozzle : From the marking on the Danfoss oil nozzles it is easy to read the capacity, spray pattern and spray angle. Some types also provide information on norm specific properties according to the norm in question, e.g. EN 293 and 299.


Marking on an oil nozzle, type OD with a capacity of 2.37 kg/h2)



EN states that the oil nozzle is in accordance with the norms EN 293 and EN 299.
80° II states the characteristic of the oil nozzle, i.e. angle index and atomizing index according to EN Norm (2).
The figures in the square brackets [ ] are an internal series code.
The USgal/h value states the oil nozzle capacity in another definition point (1), which formerly was

spread globally in the industry – and is still used in especially the customer area. To be able to meet the demands in this market, these designations will be maintained on all Danfoss oil nozzles.

1) Definition point USgal/h = 7 bar, 3.4 mm²/s, 820 kg/m³
2) Definition point kg/h according to EN 293 = 10bar, 3.4 mm²/s, 840 kg/m³

Danfoss Nozzle | Service and Storage Accessories in India

All types of Nozzles are available in India  |  We are leading importers, distributors and stockists of Danfoss Nozzle in India since 1996 - 97 (Yash Hitech Systems)



We have Danfoss oil Nozzle for Light oil burner and heavy oil burner.  Danfoss Oil Nozzles Capacity: 0.50 to 2.25 GPH suitable for all type of liquid fuel like LDO,diesel , kerosene, bio diesel , HSD, furnace oil , heavy oil , LSHS. Ready Stock Danfoss Nozzle Type S, H and B.



Oil Nozzles

Danfoss oil nozzle programme consists of a wide range for standard burner systems as well as a series of special nozzles adapted for different market demands as regards operating area, media and emission.  Nozzles in accordance with EN 293 and EN 299. Each Danfoss oil nozzle is tested 100 per cent electronically and visually for function and uniformity. Danfoss recommends to change the oil nozzle once a year out of consideration for environment and operating performance.



Other Danfoss Nozzle Product Collection in India | We are the leading Danfoss Products importer and distributors in India.

Danfoss Oil Pumps:

Danfoss oil pumps are available in different models depending upon capacity in Lph, Pressure and type of Fuel being used.
These are available in BFP, RSA and RSH series.
These are having very high quality Viton Seals and also suitable for very Light Fuels like Kerosene and 10% Bio-diesel etc.
Pump models BFP 21 R3/L3, BFP 21 R5/L5, BFP 41L3 and BFP 10L6/R6 are available Ex. Stock with us



Danfoss Burner Controller:

Models OBC 82.10 and 84.10 available in stock.
Microprocessor based controller offers Stable and Precise Timings.
Suitable for One / two stage burners upto 30 kg/hr capacity with and without preheater.

Danfoss Photocells:

Danfoss photo resistors of type LD and LDS Series are suitable for to detect flame in yellow flame burners.
These are compatible with Danfoss OBC and BHO controllers and are available in black and red color indicating normal and high sensitivity of photo resistors.
These are available in different Cable Lengths and with suitable Clamp & Flange for Mounting Purposes.

Danfoss EBI Transformers:

These are new EBI series 4 transformers of electronic type D and these are lead fee and RoHs compliant.
These are available for both Intermittent and Continuous Duty for single pole and two pole variety for small and medium Oil and Gas Burners.
Models available are EBI4 - 052F 4030 / 4038 / 4034 / 4040 / 4036 and 4031 varieties with plug in type primary cable.
These are already in built with suitable interference suppression free filters to overcome field disturbances in panels.

Danfoss Nozzle Remover, Danfoss Nozzle Adapters , Accessories for Oil Nozzles, Danfoss High-Pressure Pumps, Danfoss High-Pressure Pump Valves, Danfoss High-Pressure Pump Motors, Danfoss High-Pressure Pump Nozzles, Danfoss High-Pressure Pump  Accessories



Danfoss Nozzle Box

A sturdy, attractive, injection molded plastic box with a molded insert to accommodate 40 Nozzles in their individual containers. It has a convenient carrying handle, sturdy snap hasps and hinges. A Nozzle Pressure/Flow Chart in the lid gives quick, on the job, reference information for the serviceman. Will accommodate nozzles in any standard make container.



Danfoss oil Nozzle Holder

We are Importers, Distributors and Stockies of Danfoss Oil Nozzles in India


Office Address

YASH HITECH SYSTEMS
Gala no: U - 50 / U - 150,
Ground / First floor, Jai Matadi Compound,
Opp Rajlakshmi Complex,
Near Paliwal Milk co,
Thane - Bhiwandi Road,
Kalher, Bhiwandi - 421302,
Thane, Maharashtra.

Tel: 02522-662064, 09370136569

Mobile : 9820524582 | 9820344636

                     9323220221 | 9322310718

Email: yashhitech99@gmail.com

Fax No : 02522 - 662064

Bank Details

BANK OF BARODA



A/C Name: Yash Hitech Systems



Current Account No :





Branch: Majiwade, Thane Branch



RTGS / IFSC CODE : BARB0MAJIWA

( PLS NOTE MIDDLE IS DIGIT ZERO AND NOT ‘O’ )



MICR CODE : 400012077
